Atol 650 Price, Specs, Cabin, and Engine.Atol 650 is an amphibious light sport aircraft (LSA) developed and created by Atol Avion Ltd. This airplane can running in water, land and also snow. This airplane completed its initial trip in April 2015. The LSA went through a water transport examination for the first time in December 2014. The LSA was exhibited for the very first time at the Sodankylä Airshow in June 2015 as well as was likewise shown at the Aero 2015 exhibit in Germany.
Atol 650 Cockpit as well as Avionics
Atol 650 airplane can suit pilots and also guests in side-by-side seat arrangements. Each seat has a four-point seat belt and a shoulder band. The cabin is furnished with textile or natural leather upholstery. It was covered by a rear hinged canopy that rose with a control panel. Covers enable residents to get in or leave planes on the beach with dry feet. This includes emergency situation cover releases as well as can be secured from the outside.The Atol 650 avionics collection includes a 7 in MGL display, a 4.3 in MGL XTreme engine surveillance system, twin controls and also twin brake pedals. The cockpit is likewise furnished with a fresh air nozzle, mounted for iPad, electric outlets on the tool and top panel, electrical trim, and home heating and defogging systems.
Atol 650 Engine
Atol 650 amphibious airplane is powered by a Rotax 912iS engine which can create outout power of 100 bhp. The engine drives a set three-blades prop with an elevation of 1,720 mm. This airplane has a gas capacity of 140 liters which provides nine hours of endurance. The aircraft can fly with a cruise ship speed of 170 km/ h as well as a strike rate of 74 km/ h. It has an optimal variety of 1,500 kilometres (950 mi).
Atol 650 Specifications
The Atol 650 fuselage is made from modern-day composite timber. The measurements of the aircraft include a size of 7.45 m, a wingspan of 9 m, a wingspan of 13.5 m ², and also a tail period of 2.4 m. It includes a standard touchdown gear that can be drawn back during flight as well as water operations. It additionally includes a complementary nose wheel which aids in gliding to steep beaches. The airplane can be furnished with an Atol water taxi (AWTS) system for water maneuvers.
Atol 650 airplane have a wing folding system with a guidebook control line connection. Wing element proportion makes sure center of mass (CG) range and also ease of filling without stringent loading limitations. The wing tips are positioned at the top of the fuselage to make certain safe procedure on water, while the dihedral wing even more ensures good roll security. The airplane can be additionally equipped with skis to operate in the snow during winter.The aquatic airplane is also furnished with a bilge pump, a bulkhead in the rear body to stop the uncontrolled hull water from relocating, aft cleats, as well as mooring posts in extra buoy supporters and tails. It additionally incorporates luggage compartment, as well as integrated water guiding in the tail wheel, in addition to paddles and fasteners. The aircraft’s empty weight is 375 kg, the optimum take-off weight (MTOW) is 650 kg, and the maximum tons lugging ability is 275 kg. this airplane considers 100 kg lighter than various other LSA that is presently readily available on the marketplace.
Atol 650 Price
The rate of the most up to date Atol 650 amphibious light sporting activity airplane (LSA) is around United States $ 179,000.
