Bombardier Dashboard 8 Q400 Cockpit, Specifications, Inside, and also Rate.Bombardier Dashboard 8 Q400 is one of the quietest turboprop aircraft in the world created by Bombardier Aerospace De Havilland Canada. The advancement of this aircraft is planned to satisfy the demands of regional airline companies for larger aircraft above density paths and short ranges. Q400 is the largest member of the Dashboard 8 family that can suit up to 80 passengers.
The Q400 program was introduced in 1995 as a broad version of the Q300 series. The very first trip of the Q400 aircraft was carried out in 1998 and went into business service in February 2000. The airplane was equipped with a noise and vibration reductions (NVS) system introduced in the Dashboard 8 turboprop family members in 1996.
The latest version of the Q400 airplane, the Q400 NextGen, was revealed in March 2008. The brand-new airplane has renovations in the cabin atmosphere, including LED illumination, brand-new ceiling panels, sidewall windows as well as larger containers. Q400 NextGen took part in the 2012 FIDAE Air Program kept in Santiago, Chile in April 2012.
Bombardier Dash 8 Q400 Engine and also Efficiency
The Q400 airplane is powered by 2 PW150A turboprop engines supplied by Pratt & Whitney Canada. Each engine can producing an output power of 5,071 shp or 3,800 kW. The engine is furnished with complete digital engine control (FADEC). With the assistance of the PW150A engine, the Q400 is capable of flying with an optimum cruise ship rate of 650 kilometres/ h with a maximum distance of 2,519 kilometres.
Bombardier Dashboard 8 Q400 Specifications
The transverse section near the circle of the fuselage as well as the tail section are manufactured by Mitsubishi. The wings, tail plane, and also front end of the fins are outfitted with a de-icing system. The Q400 airplane is geared up with a R408 kind 6 bladed composite propeller provided by Dowty. The propeller is furnished with an electric existing elimination system. Generally, the Q400 airplane has a length of 32.84 m, an elevation of 8.36 m, and also a wing span of 28.42 m.
In regards to power, the Q400 airplane powered by an Allied Signal electrical power system includes two starter/ generators for DC power, two transformer systems and 2 nickel cadmium batteries. There are two engine-driven A/C generators to provide variable regularity AC power.
The Q400 airplane touchdown mechanism features a retracting Menasco tricycle kind touchdown gear. Each unit has actually twin wheels outfitted with Goodrich anti-skid brakes. 2 independent hydraulic systems are supplied by Parker Bertea Aerospace.
The fuel container situated on the wing of the airplane has an overall capability of 6,526 l. The Q400 test aircraft ended up being the very first Canadian aircraft to fly utilizing D7566 bio-fuel. D7566 is accredited by the American Society for Testing and also Materials (ASTM). Concierge Airlines is Canada’s first biofuel-powered profits trip on its Q400 aircraft.
Bombardier Dash 8 Q400 Cabin and also Inside
The Q400 aircraft cabin can be configured for a class or more class design that can hold 68 to 78 passengers. Meanwhile, cabin with organisation class arrangements can only suit 58 seats. The cabin is geared up with an air ladder mounted at the front of the cabin, allowing the aircraft to make use of the flight terminal with minimal ground assistance centers. Two passenger doors and one service door allow the aircraft to stand up and also down quickly. This aircraft provides more than 14 m ³ of baggage area.
Bombardier Dash 8 Q400 Cabin as well as Avionics
The Q400 aircraft is equipped with a double control cockpit that can fit pilot and also co-pilot. The cockpit is integrated with an electronic trip instrumentation system (EFIS) with five high-resolution LCDs, 6 in x 8 in to present all flight info. The cockpit is likewise geared up with an emergency locator transponder, strong state cabin voice recorder, as well as a holographic support system from Trip Dynamics.
The avionics collection of Q400 aircraft supplied by Thales Avionics includes a flight management system, international placing system as well as a traffic warning and also collision evasion system, TCAS II. The airplane communication collection includes twin VHF navigation and S communication and transponder setting. Navigating tools includes weather condition radar, proximity closeness alerting receivers, radar altimeters, automatic direction finders, and distance measuring devices.
Bombardier Dashboard 8 Q400 Price as well as Orders
The cost of the most recent Bombardier Dash 8 Q400 aircraft is around US $ 32.2 Million. Greater than 413 Q400s have been gotten, with 389 provided in December 2011. Major drivers include: SAS Commuter (launch consumer), Augsburg Airways from Germany, Perspective Air UNITED STATES, Austrian Tyrolean Airways, Qantas Airways, Horizon Air, Flybe, Colgan Air/ Peak, Doorperson Airways and All Nippon Airways Japan. Meanwhile orders for the NextGen Q400 consist of 20 aircraft from Eurolot in March 2012, 5 airplane for Ethiopian Airline companies and also 2 for Horizon Air in February 2012.
