Czech Sport Airplane PS-28 Cruiser Price, Specifications, and Cockpit.The PS-28 Cruiser is a two-seat low-wing lightweight sporting activity airplane established by Czech Sport Airplane. This airplane can be made use of for basic as well as advanced flight training, air clubs, fundamental armed forces pilot training, general leisure usage, and also air tourism. The PS-28 Cruiser aircraft acquired type certification from the European Aeronautics Safety And Security Agency (EASA) in April 2012 in the category of lightweight sporting activity airplane and got in service in October 2012. This aircraft is available in Standard, Style and Exclusive designs.
PS-28 Cruiser Engine as well as Efficiency
The PS-28 Cruiser is powered by a Rotax 912 ULS2/ S2 engine that can create an output power of 73.5 kW. The engine drives the Sensenich Fixed 3-blade prop. The aircraft is furnished with gas storage tanks with a complete capability of 114 l.
Rotax 912 engine assistance enables the PS-28 Cruiser to fly an optimum cruise rate of 172 km/ h and also a straight rate of 220 kilometres/ h. The aircraft has a climbing up speed of 4.2 m/ s as well as a series of 512 nm (948 kilometres). This airplane takes in fuel around 17.5 l/ h as well as has a toughness of 5 hours as well as 26 mins.
PS-28 Cruiser needs a take-off distance of 387 m on the concrete surface area and also 457 m on the surface of the lawn. On the other hand, landing an aircraft calls for a distance of 362 m on the concrete surface area and also 338 m of grass.
PS-28 Cruiser Cabin as well as Avionics
The aircraft has a large glass fiber cabin that is furnished with a primary Dynon D-100 flight data show and a Dynon D-120 engine tracking system. A big cockpit glass cover will provide best visibility for the pilot. Flight controls such as wheel brakes lie on the pedals as well as throttles are located on the center console in the cockpit.
The cabin of the PS-28 Cruiser is geared up with a contemporary as well as advanced avionics system, such as a magnetic compass, a back-up air rate indicator, as well as a navigation/ interaction radio. Various other avionics suites include the HS-34 navigation expansion component, S setting transponders as well as course 2 intercoms, as well as the Garmin 695 GPS.
PS-28 Cruiser Specifications
The PS-28 Cruiser has an all-metal airframe design, traditional cantilevered wings as well as tail. The airplane is equipped with a dealt with tricycle kind landing equipment with hydraulic brake support. The main undercarriage is affixed straight to the bottom of the body as well as the nose touchdown gear is connected to the firewall software.
The aircraft tail device contains upright fins, guiding, horizontal stabilizers and lifts with trim tabs. This lift is balanced with electrically controlled lift lifts. The lift is likewise geared up with an equilibrium tab for better control as well as balance.
The wings are geared up with electrically regulated flaps and also ailerons. The ideal aileron is furnished with an electric trim. Each wing is accepted six bolts in the center of the wing. The wing pointers are made of carbon-glass composite as well as are equipped with limelights.
This airplane can accommodate 2 guests who function as pilots. The aircraft’s inside includes 2 seats placed alongside. Leather seat seats will certainly enhance guest convenience when flying.
The dimensions of the PS-28 Cruiser airplane consist of a length of 6.62 m, an elevation of 2.31 m, as well as a wingspan of 8.6 m. The airplane’s wing surface is 12.3 m ². The aircraft has two luggage storage areas located in each wing with a capacity of 10 kg each. Various other baggage storage space areas are also available at the rear of the seat with an ability of 18 kg.
PS-28 Cruiser Cost and Orders
The rate of the current light sport aircraft PS-28 Cruiser is around United States $ 140.000. Czech Sport Aircraft received orders for 2 PS-28 Cruiser aircraft to be sent out to France in March 2013. Eindhoven Aero Club ordered the shipment of two airplane in January 2014. To day, Czech Sport Airplane has sent more than 500 aircraft to different operators all over the world.
